This article discusses the common collector amplifier which is the amplifier topologies. The common collector amplifier is one of the three basic BJT amplifier topologies. In this circuit, the base of the transistor serves as an input, emitter as the output and the collector is grounded that is, common for both emitter and base.

It is also called as an emitter follower. This configuration acts as a buffer. This circuit provides offer low output impedance while taking high input impedance. This configuration is mainly used in digital circuits with logic gates and has many applications. The load resistor in the common collector amplifier being placed in series with the emitter circuit receives both the base current and collector currents.

Op Amp applications as Inverting Amplifiers

Since the emitter of a transistor is the sum of the base and collector currents, since the base and collector currents always add together to form the emitter current, it would be reasonable to assume that this amplifier will have a very large current gain. The common collector amplifier has quite a large current gain, larger than any other transistor amplifier configuration. The characteristics of the common collector amplifier as mentioned below. The common collector characteristics are quite different from the common base and common emitter characteristics. This is because the input voltage Vbc is largely determined by the output voltage Vec.

As Vbc increases with Vec constant Veb decreases hence Ib decreases. Here as Vcc increases Ie also increases. Just as in common emitter output characteristics Ic increases with increasing Ib, so Ie also increases here with the increase in Ib. Hence, for constant Vec, Ie increases with Ib.

Cryogenic Differential Amplifier for NMR Applications

The small signal circuit performance can now be calculated. Total circuit performance is the sum of quiescent and small signal performance. The AC model circuit is shown below. The current gain is defined as the ratio of the load current to the input current. The current gain is dependent only on the BJT characteristics and independent of any other circuit element values. In the below image an ideal class A amplifier is shown. As we can see in the image, there is one active element, a transistor.

The bias of the transistor remains ON all of the time. Due to this never turn off feature, Class A amplifier provides better high frequency and feedback loop stability. Other than these advantages, Class A amplifier is easy to construct with a single-device component and minimum parts count. Despite the advantages and high linearity, certainly, it has many limitations. Due to continuous conducting nature, the class A amplifier introduce high power loss. Also, due to high linearity, Class A amplifier provides distortion and noises.

Apex Reference Products

The power supply and the bias construction need careful component selection to avoid unwanted noise and to minimize the distortion. Because of high power loss in Class A amplifier, it emits heat and requires higher heat sink space. The Class B amplifier is a bit different from the Class A. It is created using two active devices which conduct half of the actual cycle , ie degrees of the cycle. Two devices provide combined current drive for the load. In the above image, an Ideal Class B amplifier configuration has been shown.

It consists two active devices which get biased one by one during the positive and negative half cycle of sinusoidal wave and thus the signal gets pushed or pulled to the amplified level from both positive and negative side and combine the result we get complete cycle across the output. We can see each device input and output signal graph in the below image.

The heat dissipation is minimized in this class providing a low heat sink space.
